LONGi Dual Glass LR7-54HVD-475M (475W)

Solar panel · Made in CN

Check it in a full system design
LONGi Dual Glass LR7-54HVD-475M (475W)

Technical specifications

Peak power
475 Wp
Short-circuit current (Isc)
15.28 A
Open-circuit voltage (Voc)
40.86 V
Temp. coefficient of Voc
-0.2 %/°C
Series
Dual Glass

Specification provenance: Unverified imported catalogue data — per-field datasheet citations are being added as documents are processed.

Dimensions & weight

Width × Height × Depth
1800 × 1134 × 30 mm
Weight
23.5 kg

Source: read from the manufacturer's datasheet.

Downloads

Related products

Other variants in the Dual Glass family:

Frequently asked

What are the dimensions of the LONGi Dual Glass LR7-54HVD-475M (475W)?
The LONGi Dual Glass LR7-54HVD-475M (475W) measures 1800 mm wide × 1134 mm high × 30 mm deep. This figure is read from the manufacturer's datasheet.
How much does the LONGi Dual Glass LR7-54HVD-475M (475W) weigh?
The LONGi Dual Glass LR7-54HVD-475M (475W) weighs 23.5 kg (read from the manufacturer's datasheet).
Where is the LONGi Dual Glass LR7-54HVD-475M (475W) made?
Our catalogue records the country of origin for the LONGi Dual Glass LR7-54HVD-475M (475W) as CN (ISO 3166-1 alpha-2).
Where can I download the LONGi Dual Glass LR7-54HVD-475M (475W) datasheet?
The LONGi Dual Glass LR7-54HVD-475M (475W) datasheet is published by the manufacturer and linked from the Downloads section of this page. We link to the manufacturer's own copy so you always get the current revision.
